SC SC1346 RGB Camera Module Rolling Shutter 1280x720 for Biometrics

SC SC1346 RGB Camera Module Rolling Shutter 1280x720 for Biometrics

SC1346 RGB Camera Module

1280x720 RGB Camera Module

Biometrics Rolling Shutter Camera Module

Brand Name:

Chippack

Model Number:

SC1346

Chat Now
Request A Quote
Product Details
Sensor Type:
SC1346
Sensor Brand:
SmartSens
Active Array Size:
1280*720
Pixel Size:
2.65μm*2.65μm
Optical Format:
1/4.5''
Power:
5V
Shutter:
Rolling Shutter
Color:
RGB
Focus Mode:
Fixed Focus
Max Frame Rates:
60fps
Data Interface:
USB 2.0
Camera Size:
Supports Rapid Sample Customization
FOV:
DFOV:20°-180°(Optional Or Customized)
IR Filter:
Clear/650nm/850nm/940nm(Optional Or Customized)
Highlight:

SC1346 RGB Camera Module

,

1280x720 RGB Camera Module

,

Biometrics Rolling Shutter Camera Module

Payment & Shipping Terms
Product Description

SC SC1346 RGB Rolling Shutter Camera Module , Machine Vision , Biometrics , QR Code , Customization Services Available .



1. Basic Parameters:

- Resolution: 1280(H)×720(V), 1MP. It supports high-precision data acquisition and image capture, balancing clarity and data accuracy.

- Pixel Size: 2.65μm(H)×2.65μm(V). Adopting high-quality pixel design, it ensures the fineness and sensitivity of image acquisition, meeting the requirements of various imaging scenarios.

- Optical Format: 1/4.5 inch. The compact optical design enables easy integration into various miniaturized devices and improves product space utilization.

- Supply Voltage: Operating voltage is 5V. It works stably under rated voltage conditions and guarantees sensor reliability.

- Temperature Range: Operating temperature ranges from -20℃ to 70℃. With a wide operating temperature range, it adapts to diverse working environments.



2. Technical Features:

- Rolling Shutter Technology: Features a progressive exposure rolling shutter design with low imaging noise and delicate detail restoration. It boasts high circuit integration, lower power consumption and cost, ideal for high-definition imaging in static and low-speed scenarios.

- Adopting DSI-2 core technology, it rapidly captures dynamic scenes and real-time data to meet high-speed imaging and data acquisition demands, with no ghosting or stuttering and improved timeliness of data capture. It delivers balanced sensitivity and high color reproduction accuracy. Equipped with an RGB Bayer color filter, it accurately captures color information to present clear and realistic image effects, suitable for scenarios with high image quality requirements.

- Adopting CSP 29 packaging, it features compact size, high integration and strong anti-interference capability. Built-in signal conditioning effectively filters clutter interference and ensures stable data transmission and image acquisition. Meanwhile, it facilitates integration and installation for miniaturized devices and reduces the overall product design difficulty.

- SC1346 Camera Module: Compatible with standard modules with different lens configurations such as 130°, to meet diversified customer demands.



3. Application Fields:

Widely applied in biometric recognition, drones, smart home, IoT devices, machine vision, barcode scanning, factory automation and other fields.



4. Personalized Customization Services:

Custom modules can be produced tailor-made according to customer requirements to create exclusive products that perfectly match personalized needs.
