MI5100 Rolling Shutter RGB Camera Module 2592x1944 5MP With CMOS Sensor

MI5100 Rolling Shutter RGB Camera Module 2592x1944 5MP With CMOS Sensor

RGB Camera Module 2592x1944

CMOS Sensor RGB Camera Module

MI5100 Camera Module

Brand Name:

Chippack

Model Number:

MI5100

Chat Now
Request A Quote
Product Details
Sensor Type:
MI5100
Sensor Brand:
Onsemi
Active Array Size:
2592*1944
Pixel Size:
2.2μm*2.2μm
Optical Format:
1/2.5''
Power:
5V
Shutter:
Rolling Shutter
Color:
RGB
Focus Mode:
Fixed Focus
Max Frame Rates:
15fps
Data Interface:
USB 2.0
Camera Size:
Supports Rapid Sample Customization
FOV:
DFOV:20°-180°(Optional Or Customized)
IR Filter:
Clear/650nm/850nm/940nm(Optional Or Customized)
Highlight:

RGB Camera Module 2592x1944

,

CMOS Sensor RGB Camera Module

,

MI5100 Camera Module

Payment & Shipping Terms
Product Description

MI5100 RGB Rolling Shutter Camera Module , Machine Vision , Biometrics , QR Code , Customization Services Available .



1. Basic Parameters:

- Resolution: 2592 (H) × 1944 (V), 5MP. It supports resolution adjustment for multiple output formats and is compatible with various commonly used resolutions to meet imaging requirements of different scenarios.

- Pixel Size: 2.2μm (H) × 2.2μm (V). The well-proportioned pixel size combined with a high-quality CMOS sensor effectively improves imaging sharpness and picture texture, helping capture rich details.

- Optical Format: 1/2.5 inch. It adapts to a variety of imaging scenarios, balancing imaging performance and equipment integration.

- Supply Voltage: Operating voltage is 5V. It can work stably under rated voltage conditions and ensure sensor reliability.

- Temperature Range: Operating temperature ranges from -20℃ to 65℃. With a wide operating temperature range, it can adapt to diverse working environments.



2. Technical Features:

- Rolling Shutter Technology: Adopts a progressive exposure rolling shutter design, featuring low imaging noise and delicate detail restoration. It has high circuit integration with optimized power consumption and cost, suitable for high-definition imaging in static and low-speed scenarios.

- Equipped with a CMOS sensor with 5MP high-definition imaging capability, it can capture clear and delicate image details. It also delivers excellent dark current performance, enabling clear image in dim environments to meet the demands of low-light scenarios.

- Built-in Digital Signal Processor (DSP) supports programmable adjustment of multiple parameters including brightness, contrast, saturation, sharpness, white balance and exposure. It also supports functions such as gain control, exposure control, horizontal/vertical mirroring. The imaging effect can be flexibly optimized for different application scenarios to satisfy personalized usage needs. The module features a small size and compact structure, easy to embed in space-constrained devices, suitable for integration with various miniaturized products. It also boasts good environmental adaptability and long-term operational stability.

- MI5100 Camera Module: Compatible with standard modules with different lens configurations such as 78°, to meet diverse customer requirements.



3. Application Fields:

Widely applied in biometric recognition, drones, smart home, IoT devices, machine vision, barcode scanning, factory automation and other fields.



4. Personalized Customization Services:

Custom modules can be produced tailor-made according to customer requirements, providing customized products that fully match clients’ actual needs.
