RGB Rolling Shutter USB 2.0 Camera Module 96 Perspective 8.29 MP With IMX415 Sensor

RGB Rolling Shutter USB 2.0 Camera Module 96 Perspective 8.29 MP With IMX415 Sensor

Rolling Shutter USB 2.0 Camera Module

IMX415 Sensor Camera Module

RGB Camera Module 96 Perspective

Brand Name:

Chippack

Model Number:

IMX415

Chat Now
Request A Quote
Product Details
Sensor Type:
IMX415
Sensor Brand:
Sony Group Corporation
Active Array Size:
3840*2160
Pixel Size:
1.45μm*1.45μm
Optical Format:
1/2.8''
Power:
5V
Operating Temperature:
-20℃ To 50℃
Digital Signal Processor:
SPCA2688A
Shutter:
Rolling Shutter
Color:
RGB
Focus Mode:
Fixed Focus
Max Frame Rates:
90fps
Data Interface:
USB 2.0
Camera Size:
Supports Rapid Sample Customization
FOV:
DFOV:20°-180°(Optional Or Customized)
IR Filter:
Clear/650nm/850nm/940nm(Optional Or Customized)
Highlight:

Rolling Shutter USB 2.0 Camera Module

,

IMX415 Sensor Camera Module

,

RGB Camera Module 96 Perspective

Payment & Shipping Terms
Product Description

8.3MP RGB Rolling Shutter 96 Perspective USB 2.0 Camera Module With IMX415 Sensor , Customization Services Available .



1.Basic Parameters:

- Resolution: 3840 (H) × 2160 (V), 8.29 MP; compatible with mainstream resolutions for backward compatibility, meeting both high-definition imaging and multi-frame-rate output requirements.
- Pixel dimensions: 1.45 μm (H) × 1.45 μm (V), effectively enhancing light intake per pixel while balancing image resolution with low-light sensitivity.
- Optical format: 1/2.8-inch, compact and lightweight, designed for integration with miniaturized camera modules.
- Power supply voltage: The operating voltage is 5V, ensuring stable performance under appropriate voltage conditions and guaranteeing sensor reliability.

- Temperature range: The operating temperature spans from-20°C to 50°C, offering a wide temperature range that accommodates various working environments.



2.Technical Features:

- Curtain shutter technology: Featuring a line-by-line exposure curtain shutter design, it delivers low imaging noise and fine detail reproduction, with high circuit integration, optimized power consumption and cost efficiency, making it ideal for high-definition imaging in static or low-speed scenarios.
- Utilizing Sony's proprietary second-generation Exmor R back-illuminated CMOS technology, it eliminates the drawback of traditional front-illuminated sensors where circuitry obstructs the light-sensitive surface, significantly enhancing visible and near-infrared light absorption. Paired with STARVIS starlight night vision technology, it delivers clear, noise-free images even in extremely low-light conditions (0.1 lux). When combined with an infrared fill light, it enables all-weather surveillance in complete darkness, delivering exceptional imaging performance in low-light environments. The ultra-low dark current design prevents optical smear issues, ensuring pristine images when capturing moving subjects and maintaining exceptional image clarity during high-speed motion.
- Integrates core algorithms for bad pixel correction, lens shadow correction, and automatic white balance, delivering high-quality raw images without requiring external complex image processing chips. This simplifies backend circuit design and reduces overall development costs and timeframes.
- IMX415 Camera Module: Compatible with various lens configuration standards including 96mm, meeting diverse customer requirements.



3. Application Areas:

Used in biometrics, drones, smart homes, IoT devices, machine vision, barcode scanning, factory automation, and other fields.



4. Personalized Customization Services:

The modular design enables tailored production based on client specifications, delivering products precisely aligned with their needs.
