RGB IR OV2710 USB Camera Module Rolling 78 Degree View Shutter 2 MP For Machine Vision

2 MP RGB - IR Rolling 78 - Degree View Shutter Camera Module OV2710 Sensor For Machine Vision , Customization Services Available .

1.Basic Parameters:

- Resolution: 1920 (H) x 1080 (V), 2 MP, suitable for various video recording scenarios with smooth, blur-free footage.
- Pixel dimensions: 3μm (H) × 3μm (V), featuring the OmniPixel®3-HS high-sensitivity pixel technology that significantly enhances light sensitivity in low-light conditions and reduces image noise.
- Optical format: 1/2.7-inch, featuring an integrated optical path design with dual infrared chips that enables seamless day-night mode switching without separating the dual lenses.
- Power supply voltage: The operating voltage is 5V, ensuring stable performance under appropriate voltage conditions and guaranteeing sensor reliability.

- Temperature range: The operating temperature spans from-20°C to 70°C, offering a wide temperature range that accommodates various working environments.

2.Technical Features:

- Curtain shutter technology: Utilizes a curtain shutter design with sequential exposure, delivering low imaging noise and fine detail reproduction, along with high circuit integration, optimized power consumption, and cost efficiency, making it ideal for high-definition imaging in static or low-speed scenarios. - Integrated design reduces the overall module volume, simplifying assembly and lowering hardware costs. The IR650 balances color accuracy with near-infrared illumination, ensuring true-to-life colors and clear details in daytime video; the IR850 offers extended far-infrared illumination range and superior night vision penetration, enabling clear object detection even in low-light conditions.
- The camera features built-in integrated automatic exposure (AEC), automatic gain control (AGC), black sun suppression, image mirroring/facing, and image cropping functions, with support for window zoom and image translation adjustments. It offers a low-light sensitivity of up to 3700 mV/lux·sec, a signal-to-noise ratio of 40 dB, and a peak dynamic range of 69 dB, enabling seamless performance in complex lighting conditions such as strong backlighting, dim indoor environments, and nighttime illumination. The system effectively prevents overexposure under intense light and ensures vivid dark areas while preserving detailed details in both bright and shadowed scenes.
- OV2710 Camera Module: Compatible with various lens configuration standards including 78, meeting diverse customer requirements.

3. Application Fields:

Used in biometrics, drones, smart homes, IoT devices, machine vision, barcode scanning, factory automation, and other applications.

4. Personalized Customization Service:

The modular design enables tailored production according to client specifications, delivering customized solutions that meet specific needs.
