IMX179 RGB Rolling Shutter MIPI Camera Module 135 Perspective 8.26MP for Machine Vision Biometrics

IMX179 RGB Rolling Shutter MIPI Camera Module 135 Perspective 8.26MP for Machine Vision Biometrics

135 Perspective MIPI Camera Module

IMX179 Camera Module

8.26MP RGB Camera Module

Brand Name:

Chippack

Model Number:

IMX179

Chat Now
Request A Quote
Product Details
Sensor Type:
IMX179
Sensor Brand:
Sony
Active Array Size:
3288*2512
Pixel Size:
1.4μm*1.4μm
Optical Format:
1/3.2 Inches
Power:
2.8V/1.8V/1.2V
Shutter:
RS
Color:
RGB
Focus Mode:
Fixed Focus Or Auto Focus
Max Frame Rates:
30fps
Data Interface:
Up To MIPI 4 Lane
Camera Size:
Supports Rapid Sample Customization
FOV:
DFOV:20°-180°(Optional Or Customized)
IR Filter:
Clear/650nm/850nm/940nm(Optional Or Customized)
Highlight:

135 Perspective MIPI Camera Module

,

IMX179 Camera Module

,

8.26MP RGB Camera Module

Payment & Shipping Terms
Product Description

8.26 MP RGB Rolling Shutter 135 Perspective MIPI Camera Module With IMX179 Sensor , Customization Services Available .



1.Basic Parameters:

- Resolution: 3288 (H) × 2512 (V), 8.26 MP; supports multi-frame-rate output, delivering clear, detailed images with excellent detail reproduction.
- Pixel dimensions: 1.4 μm (H) × 1.4 μm (V). The refined pixel design significantly enhances image resolution, balancing clarity with light sensitivity to accurately capture fine textures while reducing blurriness and noise.
- Optical format: 1/3.2 inches; the module features a compact size and excellent compatibility, making it easily integrable into various lightweight and miniaturized devices.
- Power Supply Voltage: The core voltage is 1.2 V, the interface voltage is 1.8 V, and the analog voltage is 2.8 V, ensuring stable operation under various voltage conditions and guaranteeing sensor reliability.

- Temperature Range: Operating temperature ranges from-30°C to 85°C, providing a wide operational temperature range suitable for diverse working environments.



2.Technical Features:

- Rolling shutter technology: Utilizes a rolling shutter design with sequential exposure, delivering low image noise and fine detail reproduction, along with high circuit integration, optimized power consumption, and cost efficiency, making it ideal for high-definition imaging in static or low-speed scenarios.

- Equipped with back-illuminated CMOS sensor technology that significantly enhances light-sensitive area and light utilization efficiency, markedly improving light intake in low-light conditions and effectively reducing image noise and blur issues during nighttime or dim lighting. It delivers clear, vibrant color images even under low illumination, achieving excellent low-light performance.
- Featuring a highly integrated process design with a streamlined and optimized circuit architecture, it delivers exceptional overall power efficiency, with standby and operating power consumption significantly lower than those of image sensors in the same class. Equipped with HDR (High Dynamic Range) imaging technology, it effectively balances details between highlights and shadows, preventing overexposure in bright areas and darkening of low-light regions, thereby greatly enhancing image depth and integrity under complex lighting conditions.
- IMX179 Camera Module: Compatible with standard modules for various lens configurations including 135 format, meeting diverse customer requirements.



3. Application Areas:

Used in biometrics, drones, smart homes, IoT devices, machine vision, barcode scanning, factory automation, and other fields.



4. Personalized Customization Service:

All customized modules can be manufactured according to specific client needs, delivering tailored solutions that meet individual requirements.
