GC GC2053 RGB Rolling Shutter Sensor Camera Module 1920x1080 for QR Code

GC GC2053 RGB Rolling Shutter Camera Module , Machine Vision , Biometrics , QR Code , Customization Services Available .

1. Basic Parameters:

- Resolution: 1920(H)×1080(V), 2MP, enabling high-definition real-time image capture to meet image quality requirements in various scenarios.

- Pixel Size: 2.8μm(H)×2.8μm(V). The reasonable pixel size combined with optimized processes effectively improves light sensitivity, facilitating clear imaging in low-illumination environments, reducing noise interference, and ensuring the integrity of image details.

- Optical Format: 1/2.9 inch, compatible with multiple lens types. Lenses with different field angles can be flexibly selected according to application scenarios, balancing imaging range and image clarity to meet the integration needs of various modules.

- Supply Voltage: Core voltage 1.2V, interface voltage 1.8V, analog voltage 2.8V. The sensor can operate stably under different voltage conditions, ensuring its reliability.

- Temperature Range: Operating temperature from -20℃ to 80℃. It features a wide operating temperature range and can adapt to diverse working environments.

2. Technical Features:

- Rolling Shutter Technology: Adopting a progressive-exposure rolling shutter design, it delivers low imaging noise, fine detail restoration, high circuit integration, and optimized power consumption and cost, making it suitable for high-definition imaging in static and low-speed scenarios.

- Adopting back-illuminated or near-back-illuminated process design, it is a typical starlight-level image sensor. Under extremely low illumination of 0.001 lux to 0.01 lux (without infrared fill light, F1.0 aperture, 30fps frame rate), it can still output clear, low-noise images with identifiable details. The readout noise is <2.5e⁻ RMS, and the signal-to-noise ratio exceeds 42dB at 1/30s exposure. This effectively solves the problems of blurred imaging and excessive noise in weak light environments, making it suitable for night monitoring, low-light detection and other scenarios.

- Adopting CSP packaging with a compact size (typically approximately 3.7mm×3.7mm×0.5mm), it greatly improves PCB space utilization and simplifies module mounting processes. Meanwhile, it features excellent thermal conductivity and mechanical robustness. Some versions have passed the AEC-Q100 automotive-grade reliability test, boasting strong anti-interference and anti-vibration capabilities, ensuring stable operation under harsh working conditions and extending product service life.

- GC2053 Camera Module: Compatible with standard modules configured with lenses such as 73° to meet diverse customer needs.

 3. Application Fields:

Applied in biometric identification, unmanned aerial vehicles, smart home, IoT devices, machine vision, barcode scanning, factory automation and other fields.

4. Personalized Customization Services:

Custom modules can be produced on a customized basis according to customer needs, providing tailor-made products that meet their specific requirements.
